產品規格
| Shell Size / 外殼尺寸 | 41 |
|---|---|
| Contacts / 導梢數 | 4、8 |
| TYPE / 類型 | Plug (P) / 插頭、Receptacle (R) / 插座、Female (F) / 導梢、Male (M) / 導針、Conduit type (GP) / 軟管式 |
| Water proof / 防水 | 否 |
| RoHS / 歐盟環保指令 | RoHS 2.0 |
產品介紹
相關型號：
[ PLS-41❖-RF-R ]
[ PLS-41❖-GPM6-R ]
[ PLS-41❖-GPF6-R ]
[ PLS-41❖-RM-R ]
| ❖ No. of contacts | 4 | 8 |
|---|---|---|
| Contacts Configuration |  |
 |
| Rated current / voltage | 30A 250V | 15A 250V |
| Operating voltage limit (AC.V.rms) | 500 | 400 |
| Withstanding voltage (AC.V. rms) 1 minute | 2500 | 2000 |
| Insulation resistance (MΩ MIN.) at DC 500V | 2500 | 2000 |
| Contact resistance (mΩ MAX.) at DC 1A | 3 | 3 |
| Solder internal diameter | 5 | 3.5 |
